Agricultural Die Casting for Tractors & Irrigation

Agricultural machinery operates in the most corrosive and mechanically demanding outdoor environments in manufacturing: seasonal temperature extremes, continuous exposure to water, fertilizers, herbicides, and pesticides, vibration and shock from rough terrain, and maintenance intervals measured in seasons.

---

Agricultural Environment Requirements

Chemical resistance: Fertilizers (ammonium nitrate, urea, potassium chloride) and crop protection chemicals are aggressive electrolytes that accelerate aluminum corrosion. KastMfg specifies A360 (lower copper, better corrosion resistance than A380) for die castings in chemical contact, combined with e-coat plus powder coat for maximum barrier protection.

Vibration and fatigue: Continuous vibration at engine and terrain frequencies subjects castings to tens of millions of fatigue cycles over a tractor's service life. KastMfg evaluates rib layout, fillet radii, and wall thickness during DFM review specifically for vibration-loaded agricultural applications.

Repairability: Unlike automotive components, agricultural equipment is serviced in field workshops with limited tooling. Castings must tolerate weld repair (A360 for weldability) and re-machining of worn bearing surfaces.

IP protection: Hydraulic and electronic components require IP65/IP67 for field washing. KastMfg machines O-ring grooves and sealing faces to drawing tolerance with CMM verification and pressure test on first articles.

---

Agricultural Parts at KastMfg

Tractor and Power Unit

• Hydraulic pump and directional valve housings (A413 for pressure tightness)
• Gearbox covers and PTO housing components
• Fuel filter adapter bodies and pre-filter housings
• Air cleaner bodies and intake ducting connectors
• Differential lock actuator housings
• ISOBUS and electronics module housings (IP67, A360)

Irrigation Equipment

• Sprinkler head bodies and rotor housings
• Drip irrigation control valve bodies
• Fertigation injection system bodies
• Irrigation controller weatherproof enclosures (A360 + powder coat)
• Pump coupling and impeller housings

Sprayer and Application Equipment

• Boom spray nozzle bodies (Zamak 5 with nickel plate for chemical resistance)
• Liquid fertilizer distribution manifold bodies
• Sprayer pump housings and bypass valve bodies
• Flow control and pressure regulator bodies

Seeding and Tillage Equipment

• Seed meter housing components
• Row unit frame castings
• Coulter disc arm housings
• Depth control wheel hubs

---

Material Recommendations

Application	Alloy	Coating	Reason
General tractor housings	A380	Powder coat	Standard, cost-effective
Irrigation fittings (chemical exposure)	A360	Anodize or powder coat	Corrosion resistance
Hydraulic components	A413	None (machined faces)	Pressure tightness
Fertilizer-contact components	A360	E-coat + powder coat	Maximum corrosion protection
Small precision valves	Zamak 5	Ni plate	Thin walls, chemical resistance

---

Agricultural inquiry: casting@kastdiecast.com | +86 138 1403 4409 | No.6, Rungu Road, Nanjing, China
