KastMfg designs, builds, trials, and maintains die casting molds for aluminum, zinc, and magnesium components. We are not only a mold supplier; tooling is connected directly to our die casting production, CNC machining, and inspection teams.

This matters because the best die casting mold is designed for repeatable production, not only for a successful first sample.

---

Tooling Programs We Support

Tooling Type	Typical Use
Single-cavity die casting mold	Low to medium volume parts or larger components
Multi-cavity die casting mold	High-volume small components where cycle cost matters
Slide and core tooling	Side holes, undercuts, complex housing geometry
Insert tooling	Wear areas, threaded inserts, steel reinforcement
Tool transfer and refurbishment	Existing customer-owned die moved to KastMfg

For transferred tools, see die casting tool transfer.

---

DFM Before Tool Build

Before cutting steel, KastMfg reviews:

• Wall thickness and fill risk
• Gate location and flow path
• Draft angle and ejection direction
• Parting line and flash risk
• Machining allowance and datum strategy
• Shrinkage and distortion risk
• Surface finish and cosmetic areas

This review helps reduce sample loops and avoids tooling decisions that create permanent production problems.

---

Tooling Workflow

1. RFQ review and manufacturability comments
2. Moldflow or filling risk review when required
3. Tool design and customer confirmation
4. H13 steel machining and heat treatment
5. Assembly, fitting, and bench inspection
6. First tool trial on the production machine
7. Dimensional inspection and process adjustment
8. Tool correction if required
9. Customer sample approval
10. Production release and maintenance tracking

---

What Buyers Receive

KastMfg can provide tooling-related documentation such as:

• Tool layout and cavity information
• Tool material certificate
• Trial report and sample inspection report
• Maintenance recommendations
• Shot count tracking during production
• Tool condition report for transferred dies

All customer-paid tooling is customer-owned after full tooling payment.

---

When to Choose KastMfg for Tooling

Choose KastMfg when you need a die casting mold that will be used for real production, especially when the part also requires CNC machining, pressure testing, surface finishing, or export packaging.

For a general tooling overview, see die casting tooling.

---

Die casting mold inquiry: yaoqingpu1983@gmail.com | +86 138 1403 4409 | No.6, Rungu Road, Nanjing, China
